HID/SPP Mode and can switch.
Supports Bluetooth/2.4G wireless, 2modes for option.
Supports Handheld/Continuous/Auto-Induction , 3modes for option.
Support over sixteen different countries' keyboard layout.
Excellent decoding ability, high speed and low error rate.
Built-in 2600mAh battery, super-long standby time.
Comes with adjustable scanner stand, Base supports data transmission and battery charging.
Support for smart phones/tablets/computers; compatible for Windows /Android /IOS.
It can read not only all kinds of 1D barcodes on paper but also barcodes on the mobile phone and
computer screen, and it also can read 2D barcodes.
Can be customized according to customer demand.
Technical parameters
Product Specification: YHD-5800DB 2D Wireless Bluetooth Barcode Scanner
V28-ELEINTYHD5800DB
|
Scanner parameters: |
Transmission mode: Bluetooth/2.4G/Wired | Storage: 100,000 barcodes |
Distance: 50m/100m/1.5m | Sensor: 640 × 480 CMOS |
CPU: ARM 32-bit Cortex | Battery: 3.7V-2600mAh |
Indication: Buzzer & LED | Light aimer:617nm LED |
Resolution: 4mil | Anti-inference: 0-100000Lux Max |
Decoding speed: 500scans/sec | Illumination:6500K LEDs |
Printing Contract: ≥25% | Interface: USB, USB-COM |
Button life: 8000,000 times | Material: ABS+PC |
Trigger Mode: Handheld,Continuous,Auto-Induction |
Depth Of Field | 13mil-EAN13 | 50-250mm |
4mil-code39 | 60-100mm |
20mil-QR | 40-300mm |
10mil-PDF417 | 40-280mm |
Decode Capability: 1D: UPC-A, UPC-E, EAN-8, EAN-13, Code 128, Code 39, Code 93, Code 11, Interleaved 2 of 5, Matrix 2 of 5, Standard 2 of 5, Coda bar, MSI Plessey, RSS, etc. 2D: QR Code, Data Matrix, PDF417, Aztec code, Maxicode, etc. |
Scanning angle: Angle of rotation360°, inclination± 65°, declination ± 60° |
Working current: 3.3Vx200mA | Standby current: 18uA-5mA |
Working time: 3 to 10 days | Charging power: 5V-400mA |
Certificate: CE, FCC, RoHS, IP54 | Drop test: 2m |
