TP-Link EAP650 AX3000 Ceiling Mount WiFi 6 Access Point • Ultra-Fast WiFi 6 Speeds: Simultaneous 574 Mbps on 2.4 GHz and 2402 Mbps on 5 GHz totals 2976 Mbps WiFi speeds.† • High-Efficiency WiFi 6: More connected devices can enjoy faster speeds. • Centralised Cloud Management: Omada SDN integration manages the whole network locally or from the cloud via web UI or Omada app. • 160 MHz Channel: Double the data at peak transmission times on a single stream with HE160.‡ • Seamless Roaming: Video streams and voice calls are unaffected as users move between locations.§ • Omada Mesh: Enables wireless connectivity between access points for extended range and flexible deployment.§ • PoE+ Powered: Supports both 802.3at PoE+ and DC (adapter included) power supply for flexible installations. • Ultra-Slim Design: Φ160 mm × 33.6 mm elegant design brings more agility. HARDWARE FEATURES Interface 1× Gigabit Ethernet (RJ-45) Port (supports IEEE802.3at PoE) Button Reset Power Supply • 802.3at PoE • 12 V / 1.0 A DC (EU), 12 V / 1.5 A DC (US) Power Consumption • EU: 13.5 W • US: 14.7 W Dimensions ( W x D x H ) 6.3 × 6.3 × 1.3 in (160 × 160 × 33.6 mm) Antenna Type Internal Omni • 2.4 GHz: 2× 4 dBi • 5 GHz: 2× 5 dBi Mounting • Ceiling /Wall Mounting (Kits included) • Junction Box Mounting Package Contents • EAP650 • Power Adapter • Ceiling/Wall Mounting Kits • Installation Guide System Requirements Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Linux

V177-L-NWTL-EAP650
