Instruction:

1. Insert 4 fixation rubbers to each hole under the cup holder extension and install to the car cup holder (To make it tight, 3 jagged part of fixation rubbers may be re-arranged).

2. Press tightly the cup holder extension into the car's cup holder so it does not shake.

3. Insert the cup holder following the wide hole on cup holder extension, and rotate the cup holder to fit the hook to cup holder guard's fixed hole.

*Height control is possible in 2 steps (Rotate (15~20 degree)cup holderto fix or loose)

* To loosen the fixation, rotate to the opposite way by pressing hard.

(Not easy to unwind due to its anti-shake property)

4. Install the tray onto the cup holder. (The tray can be rotated)

5. Connect the USB cable to the port(Type-C)

under the tray, and QC3.0 adaptor for

cigarette lighter.

* Cigarette lighter adaptor for the car is sold separately (not involved).

Product Features:

Product Included:

1x User Guide

1x USB Cable(C-Type)

1x Cup Holder

1x Cup Holder Extension

4x Fixation rubbers

1x Tray

Product Specification:

KC Certification: R-R-kSp-CP2

Dimensions Diameter: ? 95mm / H : 1 2mm

Size: Cup holder 210x90x190mm

Tray 280x175x65mm

Cable: 1m

Material: PP

Weight: 400g

Package Size: 365x250x84mm

Package Weight : 650g

Product Type: WPC

Mount size : 65~90mm

Protection:

OVP(Over Voltage Protection), OTP (Over Temperature Protection), FOD(Foreign Object Detection)

Coil Type: A11 coil Power Input 5V/2A, 9V/1 .67A

Power Output: WPC 5W, 9W Charging efficiency 85.47 %

Standby Current: 29.52m A Weight 107 g

Fast Charing Mobile: iPhone XR, XS, XS Max, 8/8+, X (7.5W)

Samsung Galaxy S10/10+, S9/S9+, S8/S8+, S7/S7 Edge,

Note 5, 7, 8, 9, 10 (10W) other than normal charging

V274-VE-CP-CUPWC10W-BK
